Rectifier Diode
D25
Technica l Da ta
Typical applications : All purpose high power rectifier diodes, Non-controllable and half
controlled rectifiers . Free-wheeling diodes.
Type No.
V
RRM
V
RSM
(Volts)
(Volts)
D25/02
200
300
D25/04
400
500
D25/08
800
900
D25/12
1200
1300
D25/16
1600
1700
Symbol
Conditions
Values
I
F(AV)
Sin 180 ; Tcase = 100 °C
25 A
I
FSM
Tvj = 25 °C ; 10 ms
375 A
Tvj = 180 °C ; 10 ms
320 A
I
2
t
Tvj = 25 °C
700 A
2
s
Tvj = 180 °C
510 A
2
s
I
RRM
Tvj = 180 °C
4 mA max
V
F
Tvj = 25 °C ; I
F
= 60 A
1.55 V max
V
0
Tvj = 180 °C
0.85 V
R
0
Tvj = 180 °C
11 m
R
th(j-c)
2.0 °C/W
R
th(c-h)
1.0 °C/W
T
vj
180 °C
T
stg
-40.....+ 180 °C
Mounting torque
SI units
2 Nm
Weight
Approx
20 g
Case outline
C/P
F ea tures
· Reverse voltage upto 1600 V.
· Hermatic glass to metal seal
· C : Cathode to stud
· A : Anode to stud
PACAKAGE DEATILS
DO NOT SCALE
All Dimensions in mm
