SHANGHAI SUNRISE ELECTRONICS CO., LTD.
FEATURES
· Glass passivated junction chip
· Ideal for printed circuit board
· Reliable low cost construction utilizing
molded plastic technique
· Surge overload rating: 200 A peak
· High temperature soldering guaranteed:
250
o
C/10sec/ 0.375" (9.5mm) lead length
at 5 lbs tension
MECHANICAL DATA
· Terminal: Plated leads solderable per
MIL-STD 202E, method 208C
· Case: UL-94 Class V-O recognized flame
retardant epoxy
· Polarity: Polarity symbol marked on body
· Mounting position: Any
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
SYMBOL
D10SB
10
D10SB
20
D10SB
40
D10SB
60
D10SB
80
D10SB
100
UNITS
V
RRM
100
200
400
600
800
1000
V
V
RMS
70
140
280
420
560
700
V
V
DC
100
200
400
600
800
1000
V
V
F
V
Maximum DC Reverse Current
T
a
=25
o
C
µ
A
(at rated DC blocking voltage)
T
a
=125
o
C
µ
A
Storage and Operating Junction Temperature T
STG
,T
J
o
C
http://www.sse-diode.com
D10SB10 THRU D10SB100
-55 to + 150
(Single-phase, half-wave, 60Hz, resistive or inductive load rating at 25
o
C, unless otherwise stated, for capacitive
load,derate current by 20%)
RATINGS
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
(T
a
=70
o
C)
I
F(AV)
A
Peak Forward Surge Current (8.3ms single
half sine-wave superimposed on rated load)
I
FSM
200
A
SINGLE PHASE GLASS
Maximum Instantaneous Forward Voltage
(at forward current 5.0ADC)
10
PASSIVATED SIP BRIDGE RECTIFIER
VOLTAGE: 100 TO 1000V CURRENT: 10A
I
R
1.1
5
500
D10SB
Dimensions in inches and (millimeters)
